If you are looking for comfort and luxury along with style as you travel with your off-road toys, then choose the Venom toy hauler fifth wheel by KZ.  These luxury toy hauler fifth wheels have all of the conveniences you know and love, plus a few extra luxuries you won't believe!

Starting with the exterior, you are sure to appreciate the 8'5" wide body construction, 6-sided aluminum frame, Superflex roof membrane, and the radius, aerodynamic, fully-painted, extra-reinforced, and heavy-duty front fiberglass cap with LED accent lights. Plus there is a 40 gallon fuel station with electric pump to keep the fun going all weekend long.

There are several luxurious features found inside in each model that will make you want to choose a Venom toy hauler fifth wheel by KZ today!
  • Venom 3911TK

    Venom 3911TK Floorplan Image

    Triple slides, two entry doors, a loft, and plenty of room to spread out are ... more about Venom 3911TK

    Specifications

    Sleeps 9
    Slides 3
    Length 44 ft 4 in
    Ext Width 8 ft 5 in
    Ext Height 13 ft 4 in
    Int Height 8 ft 6 in
    Interior Color Nighthawk, Sandstorm
    Hitch Weight 3070 lbs
    Gross Weight 19000 lbs
    Dry Weight 14050 lbs
    Cargo Weight 4950 lbs
    Fresh Water Capacity 100 gals
    Grey Water Capacity 97 gals
    Black Water Capacity 57 gals
    Tire Size 16"
    Furnace BTU 35000 btu

    Similar Floorplans

  • Venom 4013TK

    Venom 4013TK Floorplan Image

    With sleeping space for eight, you can easily bring your whole family, plus a ... more about Venom 4013TK

    Specifications

    Sleeps 8
    Slides 3
    Length 45 ft 2 in
    Ext Width 8 ft 5 in
    Ext Height 13 ft 4 in
    Int Height 8 ft 6 in
    Interior Color Nighthawk, Sandstorm
    Hitch Weight 3340 lbs
    Gross Weight 19000 lbs
    Dry Weight 14760 lbs
    Cargo Weight 4240 lbs
    Fresh Water Capacity 100 gals
    Grey Water Capacity 97 gals
    Black Water Capacity 80 gals
    Tire Size 16"
    Furnace BTU 35000 btu

    Similar Floorplans

  • Venom 4020DQ

    Venom 4020DQ Floorplan Image

    This KZ Venom fifth wheel toy hauler allows you to hit the road with all the ... more about Venom 4020DQ

    Specifications

    Sleeps 10
    Slides 2
    Length 45 ft 2 in
    Ext Width 8 ft 5 in
    Ext Height 13 ft 4 in
    Int Height 8 ft 6 in
    Interior Color Nighthawk, Sandstorm
    Hitch Weight 2750 lbs
    Gross Weight 19000 lbs
    Dry Weight 13620 lbs
    Cargo Weight 5380 lbs
    Fresh Water Capacity 100 gals
    Grey Water Capacity 114 gals
    Black Water Capacity 40 gals
    Tire Size 16"
    Furnace BTU 35000 btu

    Similar Floorplans

  • Venom 3311TQ

    Venom 3311TQ Floorplan Image

    Load up your off-road toys and let your next camping trip start with the KZ ... more about Venom 3311TQ

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 8
    Slides 3
    Length 36 ft 11 in
    Ext Width 8 ft 5 in
    Ext Height 13 ft 4 in
    Int Height 8 ft 6 in
    Interior Color Nighthawk, Sandstorm
    Hitch Weight 2490 lbs
    Gross Weight 16000 lbs
    Dry Weight 12700 lbs
    Cargo Weight 3300 lbs
    Fresh Water Capacity 112 gals
    Grey Water Capacity 97 gals
    Black Water Capacity 57 gals
    Tire Size 16"
    Furnace BTU 35000 btu

    Similar Floorplans

  • Venom 3411TK

    Venom 3411TK Floorplan Image

    Hit the road with this Venom 3411TK toy hauler fifth wheel in tow knowing that ... more about Venom 3411TK

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 7
    Slides 3
    Length 39 ft 5 in
    Ext Width 8 ft 5 in
    Ext Height 13 ft 4 in
    Int Height 8 ft 6 in
    Interior Color Nighthawk, Sandstorm
    Hitch Weight 2520 lbs
    Gross Weight 16000 lbs
    Dry Weight 13300 lbs
    Cargo Weight 2700 lbs
    Fresh Water Capacity 100 gals
    Grey Water Capacity 77 gals
    Black Water Capacity 77 gals
    Tire Size 16"
    Furnace BTU 35000 btu

    Similar Floorplans

  • Venom 4011QK

    Venom 4011QK Floorplan Image

    This Venom toy hauler fifth wheel by KZ is your entertainment headquarters. With ... more about Venom 4011QK

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 9
    Slides 4
    Length 45 ft 2 in
    Ext Width 8 ft 5 in
    Ext Height 13 ft 4 in
    Int Height 8 ft 6 in
    Interior Color Nighthawk, Sandstorm
    Hitch Weight 2750 lbs
    Gross Weight 19000 lbs
    Dry Weight 14530 lbs
    Cargo Weight 4470 lbs
    Fresh Water Capacity 100 gals
    Grey Water Capacity 114 gals
    Black Water Capacity 40 gals
    Tire Size 16"
    Furnace BTU 35000 btu

    Similar Floorplans

  • Venom 4111TK

    Venom 4111TK Floorplan Image

    A bath and a half, a loft, a free-standing table with chairs, triple slides, two ... more about Venom 4111TK

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 9
    Slides 3
    Length 45 ft 1 in
    Ext Width 8 ft 5 in
    Ext Height 13 ft 4 in
    Int Height 8 ft 6 in
    Interior Color Nighthawk, Sandstorm
    Hitch Weight 3160 lbs
    Gross Weight 19000 lbs
    Dry Weight 14300 lbs
    Cargo Weight 4700 lbs
    Fresh Water Capacity 100 gals
    Grey Water Capacity 125 gals
    Black Water Capacity 85 gals
    Tire Size 16"
    Furnace BTU 35000 btu

    Similar Floorplans

  • Venom 4114TK

    Venom 4114TK Floorplan Image

    A loft, a free-standing table with chairs, triple slides, two entry doors, and ... more about Venom 4114TK

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 7
    Slides 3
    Length 45 ft 1 in
    Ext Width 8 ft 5 in
    Ext Height 13 ft 4 in
    Int Height 8 ft 6 in
    Interior Color Nighthawk, Sandstorm
    Hitch Weight 3130 lbs
    Gross Weight 19000 lbs
    Dry Weight 14400 lbs
    Cargo Weight 4600 lbs
    Fresh Water Capacity 100 gals
    Grey Water Capacity 154 gals
    Black Water Capacity 57 gals
    Tire Size 16"
    Furnace BTU 35000 btu

    Similar Floorplans

Venom Features:

Standard Features (2017)

Construction
  • 101" Wide Body Construction
  • 6-Sided aluminum frame, including welded aluminum fore & aft floor joists, sidewall framing, & roof trusses
  • Extra Reinforced Heavy-Duty Front Fiberglass Cap
  • Radius Aerodynamic Front Cap
  • 2" x 3" Fully-Welded Aluminum Floor Framing
  • 2" x 2" Fully-Welded Aluminum Sidewall Framing
  • 5" Welded Aluminum Roof Trusses
  • Lippert® Hydraulic Slide System w/Selector Valves
  • 12" Powder-Coated Steel I-Beam w/Drop Frame (160 SQ FT Pass-Thru Storage)
  • Lamilux 4000® High-Gloss Fiberglass Sidewalls
  • All Weather Insulation Package to R38 (roof, floor, garage floor end caps, holding tanks)
  • Double Insulated & Heated Holding Tanks (R38 above & below tanks)
  • Additional Outside Frame-to-Wall Floor Insulation
  • R11 2" Sidewalls (w/EGS metal backing strips)
  • One-Piece ABS Slideroom Bottoms
  • Superflex® Roof Membrane (TPO/Rubber Hybrid, 12-year warranty)
  • 45-Degree Radius Aluminum Roof Edge
  • Fully Vented Attic System
  • 3/8" Fully Walk-On Roof Decking
  • 5/8" Tongue & Groove Screwed & Glued Plywood Floor Decking
  • Metal Skirt (covering the doorside frame)
  • Pex® In-Floor Heated Waterlines & Kitchen Gray Pipes (all waterlines & drains located above all insulation)
  • Fully-Enclosed & Heated Underbelly w/Direct-Heated Holding Tanks

Exterior

  • 7,000LB Dexter® Axles w/Auto Adjusting Brakes & Height Adjusting Hangers
  • 8-Lug Heavy-Duty Aluminum Rims w/16" E-Range Radial Tires
  • EZ Flex® Rubberized Suspension
  • Aluminum 3-Step Entry w/LED Light
  • Roto-Flex® Hitch Pin
  • 100% Exterior LED Running & Taillights
  • Carefree® Electric Awning w/LED Light Bar (w/interior illuminated reminder switch)
  • Propane Bottles (2 X 30 lbs.) on Same Side for Easy Access
  • Sealed Battery Storage Compartment (no battery boxes required)
  • Triple Front Slam-Latch Baggage Doors
  • Side Slam-Latch Baggage Doors w/Gas Struts & Dual Locks
  • 50 AMP Service w/Detachable Marine Power Cord
  • Fully Painted Front Cap w/LED Accent Lights
  • Frameless Windows Throughout
  • 15,000 BTU Ducted Roof AC w/Quiet Cool (prewired for OPT ducted 15,000 BTU bedroom AC w/quiet cool)
  • Wired & Framed for OPT 3rd 15,000 BTU AC
  • 35,000 BTU Furnace w/3" x 14" In-Floor Straight Line Heating System
  • 12 GAL Gas/Electric Hot Water Heater
  • LED Entry Door Floodlight
  • (2) LED Ramp Door Lights
  • LED Docking & Sewer Hookup Lights
  • Sewer Hose Storage Tube
  • Dual Swing-Away Assist Grab Handle
  • Under-Frame Spare Tire w/Hoist
  • Roof Ladder
  • Heated Water Convenience Center (incl. black tank flush, power fresh tank water fill, winterizing system, outside shower, & dry-camping water siphon)
  • Fully-Finished Heated & Sealed Basement Storage Compartment
  • Camp Table & Patio Chairs Storage Compartment
  • Heated & Enclosed Dump Valves
  • Battery Disconnect
  • Satellite Pre-Wire in Convenience Center & Roof
  • Outside Speakers
  • Generator Prep w/Surge Protector & Dedicated 30 GAL Fuel Tank
  • 40 GAL Fuel Station w/Electric Pump

Kitchen

  • Solid Surface Countertops, Flush-Mount Stove Covers & Sink Covers w/Large Handholds
  • Large Residential Double Bowl Stainless Steel Sink
  • High-Arching, Pullout, Residential Faucet
  • 30" Microwave above Range
  • U.S. Made Large Dining Table w/Removable Leaf & 2 Heavy-Duty Chairs (2 additional folding chairs V3911TK)
  • Power Vent Kitchen Fan w/Wall Controls
  • XL Residential Size Pullout Trashcan
  • Removable Silverware Tray
  • Under-Sink Storage Shelf
  • OH Cabinets incl. Shelf & Extra-Tall Slide Lips
  • Hidden Cabinet Door Hinges
  • 5" Stainless Steel Cabinet Hardware
  • Baltic Birch Drawer Boxes
  • Heavy-Duty 100 LB Drawer Glides
  • LED Kitchen Cabinet Toe-Kicks (where applicable)
  • Kitchen Window (most models)

Interior

  • Full MyRV® Control System (monitors tank levels & battery levels, controls slide rooms, leveling system, awnings, inside/outside lighting)
  • 22 OZ Residential Carpet w/3/8" Re-bond Padding
  • XL Ceiling Crown Molding
  • Window Shades Throughout
  • 100% LED Ceiling & Cabinet Lights w/Multiple On/Off Switches
  • LED RGB Entertainment Lights
  • Extra-Large Light Switches
  • Faux Vinyl Soft Touch Ceiling
  • Deluxe Residential - Style Furniture
  • Removable Pedestal Tables in Front of Seating (based on model)
  • 40" - 48" HD LED TV on Swing Arm w/Behind - TV Storage
  • Residential Entertainment System w/Radio/Bluetooth/Sound Bar & Bass Subwoofer
  • USB Charging Station & 12V Power Outlet

Bedroom

  • XL Deep Closet w/Shoe Storage Rack (V3911TK, V4013TK)
  • Dual Washer/Dryer Prep (stacked or side-by-side)
  • XL Under-Bed Storage
  • Luxurious Bedspread & Pillow Shams
  • 3Flat Panel TV on Swing Arm
  • 60" x 80" Queen-Size Upgraded Mattress

Bath

  • Residential One-Piece FG Shower Stall w/Glass Doors & Built-In Seat
  • Shower Skylight
  • XL Solid Surface Bath Vanity w/Stainless Steel Sink
  • Porcelain Foot-Flush Toilet
  • XL Linen Cabinet
  • XL Deep Closet w/Shoe Storage Rack (V3911TK & V4013TK)
  • Extra-Wide Hallway & Pocket Door
  • Power Vent w/Wall Switch
  • Towel Bar & Towel Ring

Garage

  • Roll-Down Screen Wall
  • E-Track Tie-Down System
  • Built-In Dovetail
  • 24" Diamond Plate Wall Guards
  • Garage Entry Door
  • HD Flat Panel Garage TV on Swing Arm
  • 12V Radio/DVD Player
  • (2) Garage Ceiling Speakers
  • Speaker On/Off Switches
  • Zero Gravity Ramp Door with Easy Lift Assist

Options

Exterior
  • 6-Point Hydraulic Auto Leveling System
  • 2nd Lighted Power Garage Entry Door Awning
  • Dual Pane Frameless Windows
  • Onan® 5500 Gas Generator
  • 15,000 BTU Bedroom AC
  • 15,000 BTU Garage AC w/Load Management System
  • Slide out Cover PKG
  • Goodyear G-14 G-Rated Tires
  • Backup Camera
  • "Off the Grid" Package (includes 160W Solar Panel, Inverter and Monitor)

Interior

  • Theater Seat IPO Free-Standing Table & Chairs (V3911TK, V4111TK, V4114TK)
  • 18 CU FT 120V Residential Refrigerator w/1000W Inverter (N/A V3411TK, V4013TK)
  • 18 CU FT 4-Door RV Refrigerator (LP/Electric)
  • 30" OTR Convection Oven/Microwave IPO OTR Microwave
  • Power Vent Fan w/Wall Controls (bath, bedroom, garage)
  • Day/Night Roller Shades
  • Fireplace w/Remote (Std. on V3911TK, V4111TK, V4114TK)
  • Central Vacuum System

Bedroom

  • 72" x 80" King Size Upgraded Mattress

Garage

  • HappiJac® Electric Bed & Rollover Sofa w/Table
  • Ramp Door Patio w/Entry Steps & w/Electric Awning
  • 3-Season Patio Door IPO Roll-Down Screen Wall
  • Toy Lock
  • Removable Edged Garage Carpet Kit 10' x 8'

Bonus Features

  • 2-Year Limited Warranty (see flyer)
  • One of the Lightest, High-Profile, Wide Body, Luxury Toy Hauler Fifth Wheels in the Industry
  • K-Z has received the Dealer Satisfaction Index Award for 16 years
  • K-Z’s 44 years of stable, dedicated manufacturing experience, coupled with its predominant Amish workforce, heritage and commitment to superb quality, allow us to produce the lowest-priced luxury fifth wheel available.
Please see us for a complete list of features and available options!

All features and specifications are subject to change.



Manu-Facts:

K.Z. Inc., a subsidiary of Thor Industries Inc., is headquartered in Shipshewana, Indiana, and was founded in 1972.  We have been earning our reputation as an outstanding recreational vehicle manufacturer – largely through our commitment to quality and our attention to meeting the unique needs of customers like you.

Our mission is to continue to strive for the highest quality in our products and services, to develop new concepts and competitively priced products; applying courtesy, integrity and fairness in dealing with our customers.

2200 US 67 East Business Cleburne, TX 76031 855-867-1433
Copyright © 2016 Fun Town RV • RV Dealer Website DesignPrivacy PolicySold RVs Buy Online Now
